Introduction
Yet another I2C interface…
However our i2c-stick
aims to:
- Provide a low cost interface towards our 3.3V supplied sensors who use the I2C communication bus.
- Use as much as possible off-the-shelf available material/modules.
- Create a friction free getting starting experience.
- Enable prototyping using its small sensor boards.
- Provide a reference
code
(firmware) based on the arduino platform; snippets can be used in end-user-applications.
What is i2c-stick?
A microcontroller with on one hand a USB CDC UART and on the other a
I2C master at 3.3V.
We provide open source firmware and a user-interface to easily get
started with our I2C/3.3V based sensors.
Getting started
- Click the
open
button on the top right of the screen. - Select the serial port of the i2c-stick.
- Enable the chart (transient or spatial)
- The
Scan
button will scan the I2C bus for slaves - The
Start
button will start continuously measuring all recognised slaves - The
Stop
button will stop continuously measuring the slaves - The slaves will appear on the left column.
- The
MV
button will initiate a single ‘Measure Values’ action. - The terminal let you do other cool stuff, more on this later.
The hardware
Public off-the-shelf Hardware
- RP2040 MCU: https://www.adafruit.com/product/5056
- QWIIC Cable: https://www.sparkfun.com/products/17258
- MLX90393: https://www.adafruit.com/product/4022
- MLX90614: https://www.sparkfun.com/products/17522
- MLX90640 Small FoV: https://www.adafruit.com/product/4407
- MLX90640 Wide FoV: https://www.adafruit.com/product/4469
Melexis Sensor board Hardware
Our sensors boards minimizes the board size to the bare minimum while we maximize the capability to use the sensor boards in a prototype by having the sensor mounted at opposite site as the connector and other components.
PCB:
- MLX90632: https://github.com/melexis/i2c-stick/blob/main/mlx90632-breakout/readme.md
- MLX90614: https://github.com/melexis/i2c-stick/blob/main/mlx90614-breakout/readme.md
- MLX90640: https://github.com/melexis/i2c-stick/blob/main/mlx90640-breakout/readme.md
Disclaimer
The content of this document is believed to be correct and accurate.
However, the content of this document is furnished “as is” for
informational use only and no representation, nor warranty is provided
by Melexis about its accuracy, nor about the results of its
implementation. Melexis assumes no responsibility or liability for any
errors or inaccuracies that may appear in this document. Customer will
follow the practices contained in this document under its sole
responsibility. This documentation is in fact provided without warranty,
term, or condition of any kind, either implied or expressed, including
but not limited to warranties of merchantability, satisfactory quality,
non-infringement, and fitness for purpose. Melexis, its employees and
agents and its affiliates’ and their employees and agents will not be
responsible for any loss, however arising, from the use of, or reliance
on this document.
This document is subject to change without notice, and should not be
construed as a commitment by Melexis. Therefore, before placing orders
or prior to designing the product into a system, users or any third
party should obtain the latest version of the relevant
information.
Users or any third party must determine the suitability of the product
described in this document for its application, including the level of
reliability required and determine whether it is fit for a particular
purpose.
This document as well as the product here described may be subject to
export control regulations. Be aware that export might require a prior
authorization from competent authorities. The product is not designed,
authorized or warranted to be suitable in applications requiring
extended temperature range and/or unusual environmental requirements.
High reliability applications, such as medical life-support or
life-sustaining equipment or avionics application are specifically
excluded by Melexis. The product may not be used for the following
applications subject to export control regulations: the development,
production, processing, operation, maintenance, storage, recognition or
proliferation of:
- chemical, biological or nuclear weapons, or for the development, production, maintenance or storage of missiles for such weapons;
- civil firearms, including spare parts or ammunition for such arms;
- defense related products, or other material for military use or for law enforcement;
- any applications that, alone or in combination with other goods, substances or organisms could cause serious harm to persons or goods and that can be used as a means of violence in an armed conflict or any similar violent situation.
No license nor any other right or interest is granted to any of
Melexis’ or third party’s intellectual property rights.
This disclaimer will be governed by and construed in accordance with
Belgian law and any disputes relating to this disclaimer will be subject
to the exclusive jurisdiction of the courts of Brussels, Belgium.
The invalidity or ineffectiveness of any of the provisions of this
disclaimer does not affect the validity or effectiveness of the other
provisions. The previous versions of this document are repealed.
Melexis ©2023
IATF 16949 and ISO 14001 Certified
Products
As stated in the i2c-stick
introduction, here we focus
on our 3.3V supplied & I2C communication protocol product
portfolio.
Non-contact temperature sensors (FIR)
- MLX90632 -> https://melexis.com/mlx90632
- MLX90614 -> https://melexis.com/mlx90614
- MLX90640 -> https://melexis.com/mlx90640
- MLX90641 -> https://melexis.com/mlx90641
Magnetic Position Sensors
- MLX90393
!
-> https://melexis.com/mlx90393 - MLX90395
!
-> https://melexis.com/mlx90395 - MLX90397
!
-> https://melexis.com/mlx90397
!
: not yet supported by i2c-stick firmware V1.2.0
Firmware
The sources can be found at GitHub: https://github.com/melexis/i2c-stick/tree/main/i2c-stick-arduino
Firmware installation
The boards you get from us(Melexis) for the I2C STICK are
pre-programmed.
Meaning that this information is only needed when you buy yourself from
off the shelf resources or when you want to upgrade firmware.
Instruction
- Download the
UF2
file from the pre-compiled list below. - Press both
RST
andBOOT
button on the MCU at the same time. - Release only the
RST
button. - Then moments later release also the
BOOT
button. - Now a flash drive should appear.
- drag and drop (copy) the
UF2
file to the root of that drive. - Once this copy is finished, you are ready to use i2c-stick!
List of pre-compiled MCU
i2c-stick
: Adafruit Trinkey RP2040 QT product page
